410 Stainless Steel Coil Price

Our 410 stainless steel coil price is really competitive.Alloy 410 is a martensitic stainless steel that provides moderate corrosion resistance plus high strength and hardness. This alloy can be hardened by cold working and by heat treating and is  magnetic in both conditions. A wide of properties can be achieved with different heat treatments.

410 Stainless Steel Coil Price



Applications

Compressor parts

Chain applications

Surgical parts

Spring pins

Cutlery and other food processing applications



Chemistry Typical

Carbon: 0.15 max

Manganese: 1.00 max

Silicon: 1.00 max

Chromium: 11.50-13.50

Nickel: 0.75 max

Molybdenum: 0.50 max

Phosphorus: 0.040 max

Sulfur: 0.030 max

Copper: 0.50 max

Aluminum: 0.050 max

Tin: 0.050 max

Nitrogen: 0.080 max

Iron: Balance



Physical Properties

1) Density: 0.28 lbs/in³, 7.74 g/cm³

2) Electrical Resistivity: microhm-in (microhm-cm):

68°F (20°C): 22.5 (57.0)

3) Specific Heat: BTU/lb/°F (kJ/kg•K):

32-212°F (0-100°C): 0.11 (0.46)

4) Thermal Conductivity:BTU/hr/ft²/ft/°F (W/m•K)

At 212°F (100°C): 14.4 (24.9)

At 932°F (500°C): 16.6 (28.7)

5) Mean Coefficient of Thermal Expansion: in/in/°F (μm/m•K)

32-212°F (0-100°C): 5.5 x 10-6(9.9)

32-1200°F (0-649°C): 6.5 x 10-6(11.6)

6) Modulus of Elasticity: KSI (MPa)

29.0 x 10³ (200 x 10³) in tension

7) Properties: Annealed

8) Ultimate Tensile Strength: 65 KSI min (450 MPa min)

9) Yield Strength (0.2% offset): 30 KSI min (205 MPa min)

10) Elongation: 20% min

11) Hardness: Rb 88 max


Jawaysteel Corporation,stainless steel products supplier from China,founded in 1998, is a professional manufacturer and global exporter specializing in metal manufacture and exportation. In recent years, winged by rapid merge and expansion,Our well-equipped plant emerged in Dainan, Jiangsu Province, with two Export offices respectively located in Shanghai and HongKong catering.Export offices respectively located in Shanghai and HongKong catering to a lager scale of customers from both home and abroad under the banner of supreme service.



Knowing that Our 410 stainless steel coil price is really competitive,if you have any inquiry about Stainless steel products,please contact us,we can give you an exact quote.
